SFJZ Series Vibration Grading Screen

  • SFJZ Series Vibration Grading Screen

Short Description:

Linear vibrating screen uses vibration motor as the vibration source. It makes the material thrown above the screen and have linear motion forward.


Product Detail

Production Case

  Description

  SFJZ series vibration grading screen is mainly used for the screening and grading of grain feed in feed mills, and it can also be used for the preliminary cleaning of raw materials in feed mills.In addition, it can be widely used in the screening and grading of raw materials and finished products in grain, food, chemical, sugar, mining, papermaking and other industries.

  Performance Characteristics

  SFJZ series vibration grading screen structure compact, neat appearance, beautiful;Stable and reliable work, easy operation and maintenance;In addition, this series of vibration grading screen uses vibration motor as vibration source, small vibration, low noise, stable operation, at the same time, this series of vibration grading screen also has the screen mesh replacement convenience, large output, high screening efficiency.

  Linear vibrating screen uses vibration motor as the vibration source. It makes the material thrown above the screen and have linear motion forward. Material enters into the feeding inlet of the screening machine evenly from the feeding machine. Through several layers of screen, there have different sizes of overtails and screen underflow, which are discharged from respective exit.

  Linear vibrating screen has the features of low energy consumption, high yield, simple and whole sealing structure, easy operation, no dust spraying and automatic discharging. It is more suitable for the assembly line work.

  Main Parameter



Parameter

Model

Sifting surface(mm×mm)

Power(kW)

vibrational frequency(次/分)

Capacity(t/h)

Screen slope

SFJZ100×1

1000×1800

0.4

960

6-15

20º

SFJZ80×1

800×1800

0.4

960

4-12

20º



Vibrating screen.jpg
